ASTM A320
Atlanta Rod & Manufacturing, Inc., has been manufacturing anchor bolts, embeds, headed bolts and construction fasteners to customer specifications since 1981. With 120,000 square feet of manufacturing space we have the ability to supply large scale heavy construction projects as well as small same day specials.
The ASTM A320 specification covers alloy steel and stainless steel bolting materials for low temperature service. This standard covers rolled, forged, or strain hardened bars, bolts, screws, studs, and stud bolts used for pressure vessels, valves, flanges, and fittings. Like the ASTM A193 specification, unless otherwise specified, the 8UN thread series is specified on fastener larger than 1” in diameter.
A320 MECHANICAL PROPERTIES
Grade | Size | Tensile, ksi min | Yield, ksi min | Charpy Impact | Elong, % min | RA, %, min |
---|---|---|---|---|---|---|
L7 | up to 21/2 | 125 | 105 | -150° F | 16 | 50 |
L43 | sup a 4 | 125 | 105 | -150° F | 16 | 50 |
B8 Class 1 | all | 75 | 30 | N/A | 30 | 50 |
B8M Class 1 | all | 75 | 30 | N/A | 30 | 50 |
B8 Class 2 | Up to 3/4 | 125 | 100 | N/A | 12 | 35 |
7/8 – 1 | 115 | 80 | N/A | 15 | 35 | |
11/8 – 11/4 | 105 | 65 | N/A | 20 | 35 | |
13/8 – 11/2 | 100 | 50 | N/A | 28 | 45 | |
B8M Class 2 | Up to 3/4 | 110 | 95 | N/A | 15 | 45 |
7/8 – 1 | 100 | 80 | N/A | 20 | 45 | |
11/8 – 11/4 | 95 | 65 | N/A | 25 | 45 | |
13/8 – 11/2 | 90 | 50 | N/A |
A320 CHEMICAL PROPERTIES
Element | L7 (AISI 4140) | L43 (AISI 4340) | B8 (AISI 304) | B8M (AISI 316) |
---|---|---|---|---|
Carbon | 0.37 – 0.49% | 0.38 – 0.43% | 0.08% max | 0.08% max |
Manganese | 0.65 – 1.10% | 0.75 – 1.00% | 2.00% max | 2.00% max |
Phosphorus (max) | 0.04% | 0.04% | 0.05% | 0.05% |
Sulfur (max) | 0.04% | 0.04% | 0.03% | 0.03% |
Silicon | 0.15 – 0.35% | 0.15 – 0.35% | 1.00% max | 1.00% max |
Chromium | 0.75 – 1.20% | 0.70 – 0.90% | 18.0 – 20.0% | 16.0 – 18.0% |
Nickel | 1.65 – 2.00% | 8.0 – 11.0% | 10.0 – 14.0% | |
Molybdenum | 0.15 – 0.25% | 0.20 – 0.30% | 2.00 – 3.00% |
Grades
ASTM A320 L7 Alloy steel | AISI 4140/4142 Quenched and tempered |
ASTM A320 L43 Alloy steel | AISI 4340 Quenched and tempered |
ASTM A320 B8 Class 1 Stainless steel | AISI 304, carbide solution treated |
ASTM A320 B8M Class 1 Stainless steel | AISI 316, carbide solution treated |
ASTM A320 B8 Class 2 Stainless steel | AISI 304, carbide solution treated, strain hardened |
ASTM A320 B8M Class 2 Stainless steel | AISI 316, carbide solution treated, strain hardened |
